DMP 128 FlexPlus • Configuration Tools 84
Configuring an Internal Trigger
Multiple triggers can be configured in this dialog, but each trigger must be completely
configured before the next line appears in the configuration form.
To configure an internal trigger:
1. From the Trigger column, select the desired trigger to initiate the action.
2. From the first Type column, select the line to be associated with the selected trigger.
3. From the second Type column, select the specific line appearance to be associated
with the selected trigger.
4. From the Action column, choose a macro to be run when the selected action is
registered on the selected line appearance. After this selection is made, the next line in
the internal trigger form appears.
Deleting an Internal Trigger
After an internal trigger is configured, click the box to the left of the Trigger column and
click the Delete Current button to delete that row from the internal trigger form.
Testing a Trigger
To test a trigger action by simulating a run trigger:
1. Connect to the host device in Live mode with a TCP/IP connection.
2. Click the box to the left of the Trigger column on the trigger to be tested.
3. Click the Run Trigger button to verify the selected macro in the Action column
runs as expected.
Pushing Internal Triggers to a Host Device
When internal triggers are configured in Emulate mode and the configuration file is pushed
to a device, the internal triggers are also pushed to the device.
When configuring internal triggers in Live mode, click the Set Triggers button to push
the internal triggers to the connected device with a TCP/IP connection.
