DMP 128 FlexPlus • Remote Control and Configuration 144
Command and Response Table for DSP SIS Commands
Command ASCII command
(host to device)
Response
(device to host)
Additional description
Audio level control
NOTE: The command format is the same regardless of the control point, but the acceptable gain range varies
depending on the control point.
• The mic/line input gain range is -18 dB to +80 dB in 0.1 dB increments when the source is set to analog.
• The mic/line input gain range is -18 dB to +24 dB in 0.1 dB increments when the source is set to a
digital input (for more on changing the input source, see Input Gain Block on page23).
• The pre-mixer gain and virtual return gain range is -100 dB to +12 dB in 0.1 dB increments.
• The post-mixer trim gain range is -12 dB to +12 dB in 0.1 dB increments. Post mixer trim cannot be
muted.
• The output attenuation gain range is -100 dB to 0 dB in 0.1 dB increments.
• All responses are shown with the DMP 128 in Verbose mode 2 or 3.
Set gain level
EGX7@*X7#AU} DsGX7@*X7#] Set gain on OID X7@ to a
value of X7# dB.
Example 1
(mic/line input 1):
EG40000*120 AU} DsG40000*120]
Set the mic/line input 1 to
a level of +12.0 dB.
Example 2
(pre-mixer gain 1):
EG40100*-8 AU} DsG40100*-8]
Set pre-mixer gain 1 to a
value of -0.8 dB.
Read gain level
EGX7@AU} DsGX7@*X7#] Gain on OID X7@ is set to a
value of X7# dB.
Example 1
(mic/line input 1) :
EG40000AU} DsG40000*550]
Mic/line input 1 gain is set
to a value of +55.0 dB.
Example 2
(post-mixer gain 1) :
EG60100AU} DsG60100*55]
Output 2, post mixer gain
is set to a value of +5.5 dB.
NOTE: If the input source is set to a digital input (AT or Expansion input), use the H parameter instead of
the G parameter when setting or reading input gain level (for more on changing the input source, see
Input Gain Block on page23).
Audio Mute
Audio mute
EMX7@*1AU} DsMX7@*1] Mute audio at X7@.
Audio unmute
EMX7@*0AU} DsMX7@*0] Unmute audio at X7@.
Mute status
EMX7@ AU} DsMX7@*X7$]
Phantom Power
Enable phantom power
EZX7@*1AU} DsZX7@*1]
Phantom power is only
available on mic/line inputs
1 through 8.
Disable phantom power
EZX7@*0AU} DsZX7@*0]
Phantom power status
EZX7@AU} DsZX7@*X7$]
KEY:
X7@
= Target OID See Object ID (OID) Number Tables on page151
X7#
= Gain value Levels use a 10x multiplier system with no decimal spaces. For
example, a level of +10.4 dB would be entered as 104 and a level
of -3.2 dB would be entered as -32.
X7$
= Mute/Phantom power
status
0 = disabled
1 = enabled
