DMP 128 FlexPlus • Configuration Tools 93
IP Settings
The IP Settings tab allows the user to view and edit the IP address, gateway IP address,
subnet mask, and DHCP status of the unit. The checkbox to the left of each parameter
must be checked before any changes can be made to that parameter. Click Apply to save
the changes.
NOTES:
• Changing DHCP from On to Off resets the IP address to the factory default
(192.168.254.254).
• These settings apply to the port marked LAN (non-V model) or LAN 1 (V-model).
Figure 153. IP Settings Tab
Passwords
The Passwords tab allows the user to create or edit user and administrator passwords. An
administrator password must be created in order to create a user password. The checkbox
to the left of the password type (Admin or User) must be checked before creating or editing
passwords. Click Apply to save the changes.
NOTES:
• Passwords only apply to IP connections and can be up to 12 characters in
length.
• The factory configured password for this device has been set to the device
serial number. Passwords are case sensitive.
Figure 154. Passwords Tab
figure 143. IP Settings Tab in Device Settings Dialog Box
figure 144. Passwords Tab in Device Settings Dialog Box
