Extron electronics DMP 128 FlexPlus User Manual

DMP 128 FlexPlus • Configuration Tools 86
Managing Devices in Device Manager
To add a device:
1. Click Tools > Device Manager to open the Device Manager dialog box.
2. Click the Add Device button (see figure 142,
1
below).
Figure 142. Adding a Device
3. From the DSP Configurator splash screen drop-down, select the device to be added to
Device Manager (see figure 143,
2
below). Select Connect... to open the Connect
to device...
dialog box and directly connect with a device. When connecting directly,
DSP Configurator performs a pull of the newly connected device configuration.
4. Click OK (
3
).
Figure 143. Selecting a Device to be Added
To arrange devices into a folder:
1. From the Device Manager dialog box, click the New Folder button (see figure 144,
1
on the following page).
2. Enter a name for the folder. The text for the folder name is automatically highlighted and
ready to be edited (
2
).
NOTE: Folders can be renamed later by clicking twice on the folder name and
editing the text.
3. Press <Enter>.
4. Click and drag devices over the folder name and release to insert the devices into a
folder (
3
).
figure 132. Adding a Device
figure 133. Selecting a Device to be Added
