Extron electronics DMP 128 FlexPlus User Manual

DMP 128 FlexPlus • DSP Configurator Software 45
Aux Input Dynamics Block
Two dynamics blocks are available for each Aux input. These blocks function the same
as the mic/line input dynamics blocks (see Input Dynamics Blocks on page30 for
information on configuring the Aux input dynamics blocks).
Aux Input Ducking Block
One ducking block is available for each Aux input. This block functions the same as the
mic/line input ducking block (see Input Ducking Block on page36 for information on
configuring the Aux input ducking block).
Aux Input Automix Block
One automix block is available for each Aux input. This block functions the same as the
mic/line input automix block (see Input Automix Block on page38 for information on
configuring the Aux input automix block).
Aux Input Pre-Mixer Gain Block
The Aux input pre-mixer gain block functions the same as the mic/line input pre-mixer gain
block (see Input Pre-Mixer Gain Block on page40 for information on configuring the
Aux input pre-mixer gain block).
Virtual Returns
Virtual returns receive signal when inputs are routed to the virtual send bus (see Virtual
Send Bus on page65). Sixteen virtual return channels are available and are labeled A
through P. These channels can be used in a number of applications. For example, they can
act as an AEC reference channel or be used for sub-mix processing.
Figure 76. Virtual Returns Input Panel
figure 68. Virtual Returns Input Panel
PRELIMINARY
PRELIMINARY
