DMP 128 FlexPlus • Audio Control Panels 101
Panel ID #
Panel ID numbers (ID #) are used to identify ACP panels connected to the DMP 128
FlexPlus and are necessary for the panel to function. The ID# is set using the DIP switch
assembly on the physical ACP panel. Once the panel ID has been set on the physical
device, the ID is selected in the Configure ACPs dialog box when the panel is being
configured in DSPConfigurator (for information on how to set the panel ID #, see the
corresponding ACP panel setup guide).
ACP Panel Button Control Types
Click on a button or rotary control within the panel image to select that button for
configuration. When selected, the button or control will turn yellow to indicate that it is
active for configuration, and the Configure ACPs dialog box will populate with a series of
drop-down lists for that purpose. First, one of the following control types must be selected:
• Fixed
• Follow Selector
• Selector-Vol/Mute
There are two basic control types: Action and Selector. Action controls can be either Fixed
or Follow Selector. A button with dedicated functionality, such as a rotary knob or dedicated
volume or mute buttons, can only be configured as an Action control type.
Fixed
Buttons configured with the Fixed control type perform an action that is tied to a fixed
group, preset, or macro, and is not affected by or dependent on selections made on other
buttons. When Fixed is selected, the Configure ACPs dialog populates with a series of
drop-down list selections shown in the table below. When a selection is made in the Action
list, the Configure ACPs dialog then populates with subsequent selections.
Action Select 1 Select 2 LED Behavior
Group Mute On Mute Master — Reflects Current State
Group Mute off Mute Master — Reflects Current State
Group Mute Toggle Mute Master — Reflects Current State
Group Volume Down Volume Master — Reflects Current State
Group Volume Up Volume Master — Reflects Current State
Group Vol Rotary
(ACP 100 and VC1 only)
Volume Master — Reflects Current State
Preset Recall Preset — Reflects Current State
Preset Toggle Preset 1 Preset 2 Lit press/Unlit release
Toggles Lit/Unlit
Macro Trigger Macro — Lit press/Unlit release
Macro Toggle Macro 1 Macro 2 Lit press/Unlit release
Toggles Lit/Unlit
Figure 162. Fixed Selection Table
152 Fixed Selection Table
