DMP 128 FlexPlus • DSP Configurator Software 13
9
Exit — Closes DSP Configurator. If the current configuration has not been saved, the
Save dialog box opens and prompts the user to save the current configuration before
closing the software. Click Yes to save the file. Click No to exit the application without
saving. Click Cancel to return to the main workspace and keep the software running.
Edit
Figure 13. Edit Menu
1
Cut — Removes the configuration of selected elements in the workspace to be pasted
to other elements.
2
Copy — Copies the configuration of selected elements in the workspace to be pasted
to other elements.
3
Paste — Applies the cut or copied configuration of elements to the selected elements
in the workspace.
View
Figure 14. View Menu
1
Meter Bridge — Opens a meter bridge to view input and output activity. The meter
bridge is a floating window, allowing use of the DSP Configurator workspace while
simultaneously monitoring input and output activity.
NOTE: The meter bridge is only available in Live mode with a TCP/IP connection.
2
Re-enable All Dialogs — This option re-enables all dialog boxes that no longer
appear based on user selection (certain dialog boxes that appear are user-defeatable by
selecting a checkbox that reads Do Not Show This Dialog Again).
3
Group Controls — Opens the Group Controls dialog box to access existing group
controls and add new groups.
4
AT Meters — Opens a dialog box to select AT devices on the network. Double-click a
device to open a meter bridge dialog box that displays AT transmit (Tx) and receive (Rx)
channel levels for that device. The dialog box is a floating window, allowing use of the
main workspace while simultaneously monitoring AT levels.
5
Show All Channels — Individual channels can be hidden by user selection. This
provides options for the user to select which input and output groups are visible in the
main workspace.
figure 5. Edit Menu
figure 6. View Menu
