DMP 128 FlexPlus • DSP Configurator Software 64

Expansion Output Processing

The expansion output processing chain in DSP Configurator is represented by a string

of blocks (see figure 113 below). Each block contains a specific processor or type of

processor. Each expansion output contains the following processor chain:

1. Expansion Output Trim Block

2. Expansion Output Delay Block

3. Expansion Output Filter Block

4. Expansion Output Dynamics Block

5. Expansion Output Attenuation Block

Figure 113. Expansion Output Processing Chain

Expansion Output Trim Block

Each expansion output contains a trim block. This block functions the same as the output

trim block (see Output Trim Block on page59 for information on configuring the

expansion output trim block).

Expansion Output Delay Block

Each expansion output contains a delay block. This block functions the same as the

mic/line input delay block (see Input Delay Block on page35 for information on

configuring the expansion output delay block).

Expansion Output Filter Block

Each expansion output contains a filter block. This block functions the same as the

mic/line input filter block, except that there are 10 slots for filters (see Input Filter Block on

page24 for information on configuring expansion output filters).

Expansion Output Dynamics Block

Each expansion output contains a dynamics block. This block functions the same as the

mic/line input dynamics blocks (see Input Dynamics Blocks on page30 for information

on configuring the expansion output dynamic filter).

figure 105. Expansion Output Processing Chain

PRELIMINARY

Extron electronics DMP 128 FlexPlus User Manual
