DMP 128 FlexPlus • Configuration Tools 85
Device Manager
Device Manager is used to configure and switch between multiple devices in Live or
Emulate mode within DSP Configurator (see Live and Emulate Panel on page17).
Devices can be placed and ordered in user-created folders for easily tracking systems with
devices across multiple rooms. When Device Manager contains multiple devices, all
device configurations are saved in a single DSP Configurator file.
Select Tools > Device Manager to open the Device Manager dialog box.
Figure 141. Device Manager Dialog Box
1
Add Device Button — Click the button to open the DSP Configurator splash
screen to select another device to be configured. As a device is chosen or connected, it
is added to the Device Manager dialog box.
2
Clone Device Button —Click the button to clone the currently selected device.
When a device is cloned, information within the device configuration file is also cloned.
NOTE: If Live mode is enabled, a backup may need to be performed before the
device can be successfully cloned.
3
Remove Device Button — Click the button to remove the currently selected
device from the device manager. Select a folder and click this button to delete the folder
and all devices it contains.
4
Expand and Collapse All Buttons — Click the icon to expand all folders and
show the devices it contains. Click the to collapse all folders.
5
New Folder Button — Click the button to create a new folder to drag a device into.
6
Device List Panel — Lists the devices and folders in Live and Emulate mode. From
this panel, devices can be clicked and dragged into folders, placed in custom order,
and folders can be renamed. If the device is connected via LAN, the device IP is
displayed. Double-clicking a device in this list will initiate a pull (see Connect to a DMP
128 FlexPlus in Live Mode on page17).
The color of the icon next to a device name indicates Live or Emulate status, as well as
whether the device is configured as a Primary or Secondary EXP device. Devices with
color icons are in Live mode. Devices with grayed icons are in Emulate mode. Devices
with blue icons are configured as Secondary units (see Expansion Bus on page96).
1
Add Device Button
2
Clone Device Button
3
Remove Device Button
4
Expand and Collapse All Buttons
5
New Folder Button
6
Device List Panel
figure 131. Device Manager Dialog Box
