Extron electronics DMP 128 FlexPlus User Manual

DMP 128 FlexPlus • Remote Control and Configuration 145
Command ASCII command
(host to device)
Response
(device to host)
Additional description
Audio Group Master Commands
NOTES:
• For information on configuring groups, see Groups on page69.
• A group must have assigned members for these commands to have an effect.
• For
X7^, a positive (+) value is assumed unless a negative (-) value is specified.
• If entering an X7^ value outside the valid range for the group or outside the soft limits, the DMP 128 responds
with an E13 error (invalid parameter).
• X7^, X7&, and X7* values can be sent without leading zeroes. Responses are always 5 digits in length.
Set a group fader value
EDX7%*X7^GRPM} GrpmDX7%*X7^]
Set a group fader to a
value of X7^.
Example:
ED2*-239GRPM} GrpmD2*-293]
Set group 2 fader control
to -29.3 dB.
Increment a group fader
value
EDX7%*X7&+GRPM} GrpmDX7%*X7^] Increase the level of X7% by
X7& dB.
Example:
ED2*30+GRPM} GrpmD2*-263]
Raise the group 2 fader
3 dB from -29.3 dB (set in
example above) to -26.3
dB.
Decrement a group
fader value
EDX7%*X7&-GRPM} GrpmDX7%*X7^]
Decrease the level of the
X7% group fader by X7&
dB.
View the group fader
value
EDX7%GRPM} GrpmDX7%*X7^]
In verbose modes 0 and 1,
the response is simplified
to X7^].
Mute a group
EDX7%*1GRPM} GrpmDX7%*1]
Mute all blocks in group
X7%.
Unmute a group
EDX7%*0GRPM} GrpmDX7%*0]
Unmute all blocks in group
X7%.
View a group mute
value
EDX7% GRPM} GrpmDX7%*X7$] For group masters, X7$ is
always expressed as an
unsigned or negative value.
KEY:
X7$
= Mute status 0 = unmuted
1 = muted
X7%
= Group master group
number
1 through 64
X7^
= Group fader level dB value in 0.1 dB steps, using negative numbers and
eliminating decimal places using a 10x multiplier. -100.0dB to
+80.0 dB is represented by -1000 to 800. The valid range de-
pends on the type of gain or trim block assigned to the group
number (X7%).
X7&
= Group fader
increase/decrease
dB value in 0.1 dB steps to raise or lower a group fader. Gain uses
10x multiplier (+10 dB = 100+). + or - goes after the number.
PRELIMINARY
PRELIMINARY
