DMP 128 FlexPlus • Remote Control and Configuration 146
Command ASCII command
(host to device)
Response
(device to host)
Additional description
Audio Group Master Commands (continued)
Set soft limits
ELX7%*X7*
upper
*
X7*
lower
GRPM}
GrpmLX7%*X7**X7*]
Set the groups soft limits to
X7*
upper
and X7*
lower
.
Example:
EL2*60*-60 GRPM} GrpmL2*60*-60]
Set the upper soft limit for
the group 2 fader to +6.0
dB and the lower limit to
-6.0 dB.
View soft limits
ELX7%GRPM} GrpmLX7%*X7**X7*]
In verbose modes 0 and 1,
the response is simplified
to X7**X7*].
View group type
EPX7%GRPM} GrpmPX7%*X7(]
View group members
EOX7%GRPM} GrpmOX7%*X7@
1
*X7@
2
*...*X7@
16
]
X7@ is the control address.
In verbose modes 0 and 1,
the response is simplified
to X7@
1
* X7@
2
*...*
X7@
16
]
KEY:
X7@
= Target OID See Object ID (OID) Number Tables on page151
X7%
= Group master group
number
1 through 64
X7*
= Group fader soft limit dB value in 0.1 dB steps. Gain uses 10x multiplier (+10 dB =
100+).
X7(
= Group type 6 = gain
12 = mute
PRELIMINARY
PRELIMINARY
