DMP 128 FlexPlus • Remote Control and Configuration 147
Command ASCII command
(host to device)
Response
(device to host)
Additional description
Aux Input 1 through 8
Set source mode
EDX7@*X8&AU} DsDX7@*X8&]
Get source mode
EDX7@AU} X8&]
Set mute
EMX7@*X7$AU} DsMX7@*X7$]
Get mute status
EMX7@AU} X7$]
Set analog gain
EGX7@*X7#AU} DsGX7@*X7#]
Read gain
EGX7@AU} X7#]
Aux Output 1 through 8
Set output mode
EDX7@*X9)AU} DsDX7@*X9)]
Get output mode
EDX7@AU} X9)]
Set mute
EMX7@*X7$AU} DsMX7@*X7$]
Get mute status
EMX7@AU} X7$]
Set attenuation
EGX7@*X7#AU} DsGX7@*X7#]
Read attenuation level
EGX7@AU} X7#]
Metering
NOTE: Metering is available on all input gain and output attenuation blocks.
Read meter level
EVX7@AU} X8**X8(]
-150.0 dBFS to 0.0 dBFS
Enable meter updates
EVX7@*X8*AU} DsVX7@*X8*]
Automixer Gate Monitoring
Get current automixer
gate status
EJX7@AU} X9!]
Unsolicited automixer
gate status update
This is enabled by selecting
the Automix dialog
Monitor Gate checkbox
(see Input Automix Block
on page38).
DsV
X7@*X9@*X9%*X9^]
Signal Level Monitoring (SLM)
SLM tracks when the signal at a metered gain OID crosses a set threshold level. When SLM is enabled for an OID,
an unsolicited message is sent when the threshold level is crossed. The response includes the OID, meter on/
off status, level after the threshold was crossed, and if the level was going up or down when the threshold was
crossed.
Set SLM status
EJX7@*X9$AU} DsJX7@*X9$]
Get current threshold
status
EJX7@AU} X9$]
Unsolicited meter value
DsV
X7@*X9@*X9%*X9^]
KEY:
• Variables not defined on this page are defined on the following page.
X7@
= Target OID See Object ID (OID) Number Tables on page151
X7#
= Gain value
dB value in 0.1 dB steps. Gain uses 10x multiplier (+10 dB = 100,
-3.4 dB = -34, and so on).
X7$
= Mute status
0 = off, 1 = engaged
