DMP 128 FlexPlus • Remote Control and Configuration 148
KEY:
X8&
=
Source mode
0 = disabled
1 = File/Tone Playback: Player 1
2 = File/Tone Playback: Player 2
3 = File/Tone Playback: Player 3
4 = File/Tone Playback: Player 4
5 = File/Tone Playback: Player 5
6 = File/Tone Playback: Player 6
7 = File/Tone Playback: Player 7
8 = File/Tone Playback: Player 8
9 = USB 1 Rx: Left Channel
10 = USB 1 Rx: Right Channel
11 = USB 2 Rx: Left Channel
12 = USB 2 Rx: Right Channel
17 = VoIP Line 1 Rx
18 = VoIP Line 2 Rx
19 = VoIP Line 3 Rx
20 = VoIP Line 4 Rx
21 = VoIP Line 5 Rx
22 = VoIP Line 6 Rx
23 = VoIP Line 7 Rx
24 = VoIP Line 8 Rx
X8*
=
Updates status
0 = disabled, 1 = enabled
X8(
=
Meter level
-150.0 dBFS to 0.0 dBFS (1500 to 0000)
X9)
=
Output mode
0 = disabled
1 = USB 1 Tx: Left Channel
2 = USB 1 Tx: Right Channel
3 = USB 2 Tx: Left Channel
4 = USB 2 Tx: Right Channel
9 = VoIP Line 1 Tx
10 = VoIP Line 2 Tx
11 = VoIP Line 3 Tx
12 = VoIP Line 4 Tx
13 = VoIP Line 5 Tx
14 = VoIP Line 6 Tx
15 = VoIP Line 7 Tx
16 = VoIP Line 8 Tx
X9!
=
Gate monitoring status
0 = gate monitoring disabled, 1024 = gate monitoring enabled
X9@
=
Meter status
0 = meter off, 1 = meter on
X9#
=
Signal level when gate is
opened or closed
0000 - 1023 = gate closed, ≥1024 = gate open (
Automixer Gate
Monitoring on page147 for more information).
X9$
=
Monitoring threshold
0 = disabled, 0001-2000 = signal threshold to monitor (-0.1 to -200.0
dBFS).
X9%
=
Meter value
0000-2000 = 0.0 to -200.0 dBFS
X9^
=
Meter relative to threshold
0 = above threshold, 1 = equal to or below threshold
