DMP 128 FlexPlus • Dante Controller 112
5. The Dante Controller - Device View dialog opens. Select the device being
configured from the (Select a Dante Device...) drop-down list (see figure 172,
1
below).
Figure 172. Device View and Select a Dante Device Drop-Down
NOTES:
• If there are multiple DMP 128 FlexPlus devices connected to the network that
have not been renamed, obtain the Dante interface media access code (MAC)
address of the desired device from the white label on the rear panel of the
device in order to identify it in Dante Controller.
• There are multiple MAC addresses listed on the rear panel of a DMP 128
FlexPlus, one for the LAN port and one for the Dante interface. The Dante
interface MAC address is listed beneath the LAN port MAC address.
The Device View dialog populates with the selected DMP 128 FlexPlus information.
Figure 173. Populated Device View Dialog Box
6. Click the Device Config tab (see figure 174,
1
below) to open the Device Config
page.
7. In the Rename Device panel, enter the new name of the device in the text field. No
spaces are allowed in the name. Names should be significant identifiers. For example,
enter DMP128FlexPlus-MainRack (
2
).
8. Click Apply (
3
). A confirmation prompt opens.
Figure 174. Device Config Dialog, Rename Device
162 Device View and Select a Dante Device Drop-Down
163 Populated Device View Dialog Box
164 Device Config, Rename Device
