Extron electronics DMP 128 FlexPlus User Manual

DMP 128 FlexPlus • Dante Controller 114
Renaming a Receiver
The default names shown in the Dante Receivers column are extracted from the Dante
interface of the connected device (see figure 176,
1
). The DMP 128 FlexPlus receivers are
labelled EXP_In-01 through EXP_In-48 because the DMP 128 FlexPlus can receive signal
at the 48 EXP inputs. Follow the instructions on the next page to rename a receiver.
To rename a DMP 128 FlexPlus receiver:
1. From the Device menu on the Network View screen, select Device View, or press
<Ctrl+D> on the keyboard. The Device View dialog box opens.
2. From the (Select a Dante Device..) drop-down menu, select the name of the
desired DMP 128 FlexPlus (see figure 177,
1
below).
3. On the Device View screen, select the Receive tab (
2
).
4. Click on the name of the receiver to be renamed. The name becomes a text box with a
cursor (
3
).
5. Enter the new name (up to 31 characters) using any combination of letters, numbers,
and special characters except for @, =, and . (period).
6. Press <Enter> on the keyboard to confirm the name, or click another channel text box.
7. Repeat steps 4 through 6 to rename additional receiver channels.
8. When finished renaming receivers, close the Device View dialog box.
Figure 177. Device View Screen — Renaming a Receiver
Renaming a Transmitter
The default names shown in the Dante Transmitters column are extracted from the Dante
interface of the connected device (see figure 176,
2
on the previous page). The first set
of DMP 128 FlexPlus transmitters is labelled Output-01 through Output-08 because the
DMP128 FlexPlus can transmit signal routed to the analog outputs to the Dante network.
The second set of DMP 128 FlexPlus transmitters is labelled EXP-Out-01 through
Exp_Out-16 because the DMP 128 FlexPlus can transmit signal routed to the EXP outputs
to the Dante network. Follow the instructions on the next page to rename a transmitter.
To rename a DMP 128 FlexPlus transmitter:
1. Select Device View from the Device menu on the Network View screen or press
<Ctrl+D> on the keyboard. The Device View dialog box opens.
2. From the (Select a Dante Device...) drop-down menu, select the name of the
DMP 128 FlexPlus (see figure 178,
1
on the next page).
3. On the Device View screen, select the Transmit tab (
2
).
4. Click in the ChannelLabel column to the right of the name of the transmitter being
renamed. A text box and cursor appear (
3
).
5. Enter a new name (up to 31 characters) using any combination of letters, numbers, and
special characters except for @, =, and . (period).
167 Device View Screen Renaming a Receiver
PRELIMINARY
PRELIMINARY
