DMP 128 FlexPlus • Remote Control and Configuration 150
Command ASCII command
(host to device)
Response
(device to host)
Additional description
Unsolicited Responses
Busy
VoipBusy
X!,X@]
Rejected
VoipRejected
X!,X@]
Unreachable
VoipUnreachable
X!,
X@]
Terminated
VoipTerminated
X!,
X@]
Incoming
VoipIncoming
X!,
X@,X1),X2#,X1!]
Registration status
VoipRS
X!,X1@]
Line Status
VoipLS
X!,X1$,X1$,
X1$,X1$,X1$,X1$,
X1$,X1$]
Each X1$ entry represents
an appearance of the line.
Line Status Queries (get only)
Registration status
ERSX!VOIP} VoipRSX!,X1@]
Line status
ELSX!,X@VOIP} VoipLSX!,X@,X1$]
Line status (without
index)
ELSX! VOIP} VoipLSX!,X1$,X1$,
X1$,X1$,X1$,X1$,
X1$,X1$]
Each X1$ entry represents
an appearance of the line.
Caller name
ENAMEX!,X@VOIP} VoipNAMEX!,X@,X1),X2#]
Duration
EDURX!,X@VOIP} VoipDURX!,X@,X1^]
Codec
ECDX!,X@VOIP} VoipCDX!,X@,X1&]
Jitter Rx
EJRX!,X@VOIP} VoipJRX!,X@,X1*,
X1(,X2@]
Line Extension
ELEX!VOIP} VoipLEX!,X2#,X1)]
KEY:
X!
= Line number 1 - 8
X@
= Appearance number 1 - 8 (where 1 is the originating two-party call)
X1)
= Display name Any commas returned will be displayed as hyphens (-)
X1!
= Timestamp Example: Date: Thu, 08 Sep 2017 16:24:35 GMT
X1@
= Registration status 0 = Unregistered, 1 = Registered to 1st proxy, 2 = Registered to
2nd proxy, 3 = None, 4 = Not registered (failed)
X1$
= Call status 0 = None, 1 = Inactive, 2 = Active, 3 = On Hold, 4 = Incoming,
5 = Outgoing
X1^
= Duration
HH:MM:SS
X1&
= Codec name Alphanumeric characters only
X1*
= Jitter in milliseconds
X1(
= Packet drop count
X2@
= Total packet count
X2#
= Extension number Valid characters are 0 - 9, *, #
