DMP 128 FlexPlus • Remote Control and Configuration 157
Aux Input to Analog and Aux Output Mix Matrix
Out 1 Out 2 Out 3 Out 4 Out 5 Out 6 Out 7 Out 8 Aux
Out 1
Aux
Out 2
Aux
Out 3
Aux
Out 4
Aux
Out 5
Aux
Out 6
Aux
Out 7
Aux
Out 8
Aux 1 21200 21201 21202 21203 21204 21205 21206 21207 21208 21209 21210 21211 21212 21213 21214 21215
Aux 2 21300 21301 21302 21303 21304 21305 21306 21307 21308 21309 21310 21311 21312 21313 21314 21315
Aux 3 21400 21401 21402 21403 21404 21405 21406 21407 21408 21409 21410 21411 21412 21413 21414 21415
Aux 4 21500 21501 21502 21503 21504 21505 21506 21507 21508 21509 21510 21511 21512 21513 21514 21515
Aux 5 21600 21601 21602 21603 21604 21605 21606 21607 21608 21609 21610 21611 21612 21613 21614 21615
Aux 6 21700 21701 21702 21703 21704 21705 21706 21707 21708 21709 21710 21711 21712 21713 21714 21715
Aux 7 21800 21801 21802 21803 21804 21805 21806 21807 21808 21809 21810 21811 21812 21813 21814 21815
Aux 8 21900 21901 21902 21903 21904 21905 21906 21907 21908 21909 21910 21911 21912 21913 21914 21915
Aux Input to EXP Output Mix Matrix
EXP
Out 1
EXP
Out 2
EXP
Out 3
EXP
Out 4
EXP
Out 5
EXP
Out 6
EXP
Out 7
EXP
Out 8
EXP
Out 9
EXP
Out10
EXP
Out11
EXP
Out12
EXP
Out13
EXP
Out14
EXP
Out15
EXP
Out16
Aux 1 21232 21233 21234 21235 21236 21237 21238 21239 21240 21241 21242 21243 21244 21245 21246 21247
Aux 2 21332 21333 21334 21335 21336 21337 21338 21339 21340 21341 21342 21343 21344 21345 21346 21347
Aux 3 21432 21433 21434 21435 21436 21437 21438 21439 21440 21441 21442 21443 21444 21445 21446 21447
Aux 4 21532 21533 21534 21535 21536 21537 21538 21539 21540 21541 21542 21543 21544 21545 21546 21547
Aux 5 21632 21633 21634 21635 21636 21637 21638 21639 21640 21641 21642 21643 21644 21645 21646 21647
Aux 6 21732 21733 21734 21735 21736 21737 21738 21739 21740 21741 21742 21743 21744 21745 21746 21747
Aux 7 21832 21833 21834 21835 21836 21837 21838 21839 21840 21841 21842 21843 21844 21845 21846 21847
Aux 8 21932 21933 21934 21935 21936 21937 21938 21939 21940 21941 21942 21943 21944 21945 21946 21947
Aux Input to Virtual Send Mix Matrix
A B C D E F G H I J K L M N O P
Aux 1 21216 21217 21218 21219 21220 21221 21222 21223 21224 21225 21226 21227 21228 21229 21230 21231
Aux 2 21316 21317 21318 21319 21320 21321 21322 21323 21324 21325 21326 21327 21328 21329 21330 21331
Aux 3 21416 21417 21418 21419 21420 21421 21422 21423 21424 21425 21426 21427 21428 21429 21430 21431
Aux 4 21516 21517 21518 21519 21520 21521 21522 21523 21524 21525 21526 21527 21528 21529 21530 21531
Aux 5 21616 21617 21618 21619 21620 21621 21622 21623 21624 21625 21626 21627 21628 21629 21630 21631
Aux 6 21716 21717 21718 21719 21720 21721 21722 21723 21724 21725 21726 21727 21728 21729 21730 21731
Aux 7 21816 21817 21818 21819 21820 21821 21822 21823 21824 21825 21826 21827 21828 21829 21830 21831
Aux 8 21916 21917 21918 21919 21920 21921 21922 21923 21924 21925 21926 21927 21928 21929 21930 21931
