FARO Edge
September 2012
132
Chapter 7: Software
• Pull away from the edge, and press the RED button to define probe
compensation and complete the measurement.
• Look at the plane results. Press the GREEN button to accept, or the RED
button to reject and remeasure.
3 Touch OK
4 Touch the L
ABEL field to change the feature name. Touch the NOMINALS
icon to enter nominal values. See “Nominals” on page 143.
See measuring “Point” on page 139, and “Line” on page 137.
Point: Project to Plane
From the MAIN menu, touch CONSTRUCT > FEATURES > POINT >
PROJECT TO PLANE. Use this command to construct a point from a point and a
plane.
1 Choose an existing plane in the P
OINT drop-down list or touch the MEASURE
NOW icon to measure the point:
• Place the ball probe on the part and digitize points by pressing the GREEN
button. You must digitize at least one point. Hold the RED button to remove
any unwanted points.
• Pull away from the face, and press the RED button to define probe
compensation and complete the measurement.
• Look at the point results. Press the GREEN button to accept the length, or
the RED button to reject and remeasure.
2 Choose an existing plane in the P
LANE drop-down list or touch the MEASURE
NOW icon to measure the plane:
• Place the ball probe on the part and digitize points by pressing the GREEN
button. You must digitize at least three points for a plane. Hold the RED
button to remove any unwanted points.
• Pull away from the face, and press the RED button to define probe
compensation and complete the measurement.
• Look at the plane results. Press the GREEN button to accept, or the RED
button to reject and remeasure.
3 Touch OK
4 Touch the L
ABEL field to change the feature name. Touch the NOMINALS
icon to enter nominal values. See “Nominals” on page 143.
See measuring “Point” on page 139, and “Plane” on page 138.
08M52E00_FaroArm_Edge.book Page 132 Thursday, October 4, 2012 9:31 AM
