Chapter 10: Configuring the FARO Edge in CAM2 Measure
Hole Method - Guidance
Perform the Hole Compensation using the FARO probe compensation cone. If
the G
UIDANCE check box is selected for the current probe, use the following
steps. See “Edit Probe” on page 180.
Figure 10-5 Hole Method
Position #1
Position #2
Position #3
