FARO Edge
September 2012
26
Chapter 2: Setup
Edge Power Supply
Power the Edge with the supplied power supply. The power supply is NRTL
Listed for US and Canada. For IEC member countries and Europe, the power
supply must be certified for the country in which the equipment is sold. Contact
FARO’s Customer Service to order a replacement. All servicing should be
referred to qualified service personnel.
CAUTION: INDOOR USE ONLY
Supplying Power to the Edge
Place the Edge in an area with a properly grounded outlet
receptacle. The On/Off switch is located on the back side of the
base. Ensure the On/Off switch is in the OFF position before
supplying power. Connect the power supply cord to the port on the
back side of the base.
Rated Voltage: 100 - 240V ~ 47 - 63 Hz
Voltage Tolerance: +10% or -10%
Rated Input: 1.4A
Sec. Voltage: +18 VDC
Sec. Current: 3.6A
Pollution Category: 2
Installation Category: 2
On/Off Switch
Power Supply Port
Figure 2-17 Edge Power
