FARO Edge
September 2012
162
Chapter 7: Software
• Digitize 11 points around the top hemisphere of the
sphere with the probe pointing in position #1. Hold
the handle in the same direction and orientation for
every point.
• Rotate the handle 90 degrees. Digitize 11 points
around the top hemisphere of the sphere with the
probe pointing in position #1. Hold the handle in the
same direction and orientation for every point.
• Digitize 11 points around the front hemisphere of the
sphere with the probe pointing in position #2. Hold
the handle in the same direction and orientation for every point.
• Rotate probe 90 degrees. Digitize 11 points around the front hemisphere of
the sphere with the probe pointing in position #2. Hold the handle in the
same direction and orientation for every point.
4 Look at the compensation results. Press the GREEN button to accept, or the
RED button to reject and remeasure.
For more information, see “Sphere Compensation Method” on page 187.
Position #1
Position #2
