Chapter 1: Introduction
 Tube 1
 Tube 2
 Probe
 Buttons
 Handle
 7-Axis Handle (Removable)
 Locking Button
 Status Panel
 Fold-Down Touch Screen Controller
 USB Drive Port
 SD RAM Card Port
 Base Collar
N
OTE: Newer Edge revisions do not have the  Locking Button.
Figure 1-1 FARO Edge front view












