FARO Edge
September 2012
6
Chapter 1: Introduction
 Battery Pack
 Battery Pack Release Lever
 Base Collar
 SD RAM Card Port
 USB Drive Port
 Fold-Down Touch Screen Controller
 Locking Button
N
OTE: Newer Edge revisions do not have the  Locking Button.
Figure 1-3 FARO Edge Base








