Chapter 4: Landing Gear
103
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4010200_1 NOSE WHEEL
Part
Number
Description
Q-ty per
ASSY
Unit
C9996037 Bolt DIN 912 M5x20-8.8 6 pcs
C9996563 Washer DIN 9021-5.3mm VZ 6 pcs
C9996333 Self-locking nut DIN 985-M5, regular 6 pcs
C9997205A Tyre 6-ply 4.00-4” Kenda 1 pcs
C9997207X Tube 4.00-4 valve JS 87N 90/90 1 pcs
C9997208A Front wheel 4.00-4’’with bearings for 15 mm axis 1 pcs
C9997207X
C9997205A
C9996037
FIRST S/N 03-02-04-07
C9997208A
C9996333
C9996563
C9997208A
