FLIGHT DESIGN CT2K - Spring Unit_1

Chapter 4: Landing Gear
108
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
SPRING UNIT_1 FIRST S/N 04-05-04
Part Number Description
Q-ty per
ASSY
Unit
C9996336 Self-locking nut DIN 985-M8, regular 2 pcs
C9996567 Washer DIN 9021-8.4 mm VZ 1 pcs
C9997730P O-Ring 1/2”x8mm 2 pcs
KA4010141_2 Pin 1 pcs
C9997702A Compression spring 5,50x22,50x136,0 1 pcs
C9997730P
C9996567
C9996336
KA4010141_2
C9997702A
