FLIGHT DESIGN CT2K - KA6010100 - Throttle Box (2)

Chapter 6: Flight Control
184
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number
Description
Q-ty per
ASSY
Unit
KA6010101 Body 1 pcs
KA6010107 Bolt M8x39 1 pcs
KA6010108 Bolt M8x82 1 pcs
KA6010110
Choke 1
pcs
KA6010120 Trimm 1 pcs
KA6010126 Trim tab control lever 1 pcs
KA6010130 Throttle 1 pcs
KA6010140 Brake 1 pcs
KA6010151 Main plate 1 pcs
KA6010152 Fixation angle 2 pcs
KA6010156 Fixation plate 1 pcs
C9996035 Bolt DIN 912 M5x16-8.8 4 pcs
C9996037 Bolt DIN 912 M5x20-8.8 2 pcs
C9996039 Bolt DIN 912 M5x30-8.8 2 pcs
C9996042 Bolt DIN 912 M5x45-8.8 1 pcs
C9996333 Self-locking nut DIN 985-M5, regular 9 pcs
C9996336 Self-locking nut DIN 985-M8, regular 2 pcs
C9996503 Washer DIN 125 A2-5.3mm 5 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 4 pcs
C9996563 Washer DIN 9021-5.3mm VZ 2 pcs
C9996650 Stainl. steel rivet A2 4x7.5 2 pcs
KA6010101
KA6010107
KA6010108
KA6010110
KA6010120
KA6010130
KA6010140
KA6010152
KA6010126
C9996336
C9996505
C9996650
KA6010100 - THROTTLE BOX (2)
