Chapter 5: Power Plant
149
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number
Description
Q-ty per
ASSY
Unit
KA5040003 Ear-ring 1 pcs
KA5040005 Bracket 1 pcs
KA5040006 Bush 1 pcs
KA5040004 Lower support 2 pcs
C9996095 Bolt DIN 912 M10x50-8.8 1 pcs
C9996283 Bolt DIN 933 M5x16-8.8 2 pcs
C9996333 Self-locking nut DIN 985-M5, regular 2 pcs
C9996503 Washer DIN 125 A2-5.3mm 2 pcs
C9996511
Spring washer DIN7980 M10 mm VZ 2 pcs
C9996333
C9996503
KA5040005 C9996283
C9996511
C9996095
KA5040003
KA5040006
KA5040004
BRACKETS INSTALLATION
