Chapter 4: Landing Gear
109
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4010100-04
Part Number Description
Q-ty per
ASSY
Unit
KA4010100-04 Strut, Nose Gear 1 pcs
KA4010200-04 Nose wheel, Tundra 1 pcs
KA4010002-04 Axis, Nose Wheel 1 pcs
KA4010003-04 Bush 1 pcs
KA4010216-04 Bush 1 pcs
C9996338 Self-locking nut DIN 985-M12, regular 1 pcs
C9996507 Washer DIN 125 A-13 mm VZ 1 pcs
C9996338
KA4010002-04
KA4010003-04
C9996507
KA4010216-04
KA4010200-04
KA4010200-04 - NOSE WHEEL MOUNTING, TUNDRA
