FLIGHT DESIGN CT2K - Aileron

Chapter 2: Wings
83
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Aileron
Part Number Description
Q-ty per
ASSY
Unit
KB2030100L Aileron, left 1 pcs
KB2030100R Aileron, right 1 pcs
KA2030010L Aileron pivot No1, left 1 pcs
KA2030010R Aileron pivot No1, right 1 pcs
KA2030020L Aileron pivot No2, left 1 pcs
KA2030020R Aileron pivot No2, right 1 pcs
C9996220 Bolt DIN C9997991 M6x55-8.8 1 pcs
C9996221 Bolt DIN C9997991 M5x16 A2 2 pcs
C9996286K Bolt DIN 912 M6x16, A2 2 pcs
C9996504 Washer DIN 125 A2B-6.4mm 1 pcs
C9996565 Washer DIN 9021-6.4mm VZ 1 pcs
C9997006A Rod end bearing, ext. thread GA6 1 pcs
KA2030010L
KA2030010R
C9996220
C9996221
C9996504
C9996565
C9997006A
KA2030020L
KA2030020R
C9996286K
