Chapter 1: Fuselage
37
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA1040100 BAGGAGE HATCHES
Part Number Description
Q-ty per
ASSY
Unit
KA1040100L Baggage door, left 1 pcs
KA1040100R Baggage door, right 1 pcs
KA1040300 Lock 1 pcs
KA1040303 Handle 1 pcs
KA1040304 Handle receptacle 1 pcs
KA1040305 Plate 1 pcs
C9993190H PTFE tube 6x1 0.4 m
C9993881 Line Dyneema 1.5mm blue 0.75 m
C9996704A Rivet Aluminium 3.0 x 6.0 2 pcs
C9996561 Washer DIN 9021-3.2mm VZ 2 pcs
KA1040300
C9993881
KA1040100
KA1040305
C9996561
C9996704A
