FLIGHT DESIGN CT2K - Side Wing Cap

Chapter 7: Systems
297
Release 5. Issue 21.January.2008Copyright © 2008 Flight Design GmbH. All Rights reserved
Part Number Description
Q-ty per
ASSY
Unit
KA7020002R Cap plate 1 pcs
KA7020003 Connection pipe 2 pcs
KA7020009 Rubber seal ring 1 pcs
KA7020030R Fuel intake 1 pcs
C9993184A Fuel tube DIN 73379, 7.5x13.0 0.09 m
C9993194H PU hose 1/2” OD x 3/8” ID 0.2 m
C9996309 Nut M10x1 1 pcs
C9996334 Self-locking nut DIN 985-M6, regular 6 pcs
C9996504 Washer DIN 125 A2B-6.4mm 6 pcs
C9997715G Clamp 13 mm 2 pcs
C9997715H Clamp 14 mm 2 pcs
SIDE WING CAP
KA7020002R
KA7020030R
C9993184A
KA7020003
C9993194H
KA7020009
C9996334
C9997715G
C9997715H
C9996309
C9996504
