FLIGHT DESIGN CT2K - KA3020020, KA3020030 - Rudder Lower Support & Pivot

Chapter 3: Stabilizer & Rudder
96
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number
Description
Q-ty per
ASSY
Unit
KA3020020 Support 1 pcs
KA3020030 Pivot lower 1 pcs
KA6050001 Bush 4 pcs
C9996218 Bolt DIN 7991 M6x30-8.8 2 pcs
C9996284 Bolt DIN 933 M6x16-8.8 1 pcs
C9996283 Bolt DIN 933 M5x16-8.8 8 pcs
C9996334 Self-locking nut DIN 985-M6, regular 1 pcs
C9996504 Washer DIN 125 A2B-6.4mm 1 pcs
C9996509 Spring washer DIN7980 M6 mm VZ 1 pcs
KA3020020, KA3020030 - RUDDER LOWER SUPPORT & PIVOT
KA3020020
KA3020030
C9996284
C9996218
KA6050001
C9996283
C9996334
