FLIGHT DESIGN CT2K - Roller Installation

Chapter 1: Fuselage
46
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
ROLLER INSTALLATION
Part
Number
Description
Q-ty per
ASSY
Unit
KA1060104 Roller 2 pcs
KA1060105 Axis 2 pcs
KA1060106 Pin 2 pcs
C9993172F Shrinking hose 6.4-3.2 0.07 m
C9993190H PTFE tube 6x1 0.215 m
C9997031 Lock ring DIN 471-14x1 2 pcs
C9997051 Nicopress oval sleeve 1.5-1.7 mm for 1.6mm cable 2 pcs
C9997065D Steel rope 7x7 1.6 mm 0.8 m
C9997702C Compression spring 1x8x28.5x8.5 2 pcs
KA1060104
KA1060105
KA1060106
C9993172F
C9993190H
C9997031
C9997051
C9997065D
C9997702C
