FLIGHT DESIGN CT2K - Curtain Mounting

Chapter 1: Fuselage
18
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number
Description
Q-ty per
ASSY
Unit
KB1000420 Frame 2 curtain 2 pcs
KB1000520 Frame 3 curtain 1 pcs
C9996040 Bolt DIN 912 M5x35-8.8 2 pcs
C9996283C Bolt DIN 933 M5x20-8.8 4 pcs
C9996333 Self-locking nut DIN 985-M5, regular 2 pcs
C9996563 Washer DIN 9021-5.3mm VZ 12 pcs
C9996836 Blind nut M5-9x15 4 pcs
CURTAIN MOUNTING
KB1000520
KB1000420
