FLIGHT DESIGN CT2K - T- Bracket Installation

Chapter 6: Flight Control
233
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
T- BRACKET INSTALLATION
Part
Number
Description
Q-ty per
ASSY
Unit
KA6030007 Bush 2 pcs
C9996042 Bolt DIN 912 M5x45-8.8 4 pcs
C9996064 Bolt DIN 912 M6x60-8.8 2 pcs
C9996333 Self-locking nut DIN 985-M5, regular 4 pcs
C9996334 Self-locking nut DIN 985-M6, regular 2 pcs
C9996503 Washer DIN 125 A2-5.3mm 4 pcs
C9996504 Washer DIN 125 A2B-6.4mm 2 pcs
C9996563 Washer DIN 9021-5.3mm VZ 4 pcs
C9996565 Washer DIN 9021-6.4mm VZ 2 pcs
KA6030007
C9996064
C9996565
C9996042
C9996563
C9996503
C9996333
C9996504
C9996334
