FLIGHT DESIGN CT2K - KA7040200 - Thermic Choke Connection

Chapter 7: Systems
331
Release 5. Issue 21.January.2008Copyright © 2008 Flight Design GmbH. All Rights reserved
Part
Number
Description
Q-ty per
ASSY
Unit
KA7040200 Thermic choke 1 pcs
C9993190H PTFE tube 6x1 0.65 m
C9997065B Steel rope 7x7 1 mm 0.75 m
C9997703B Spring 0,5x5,0x25,0 1 pcs
C9997723 Clamp 40-60 1 pcs
C9997816C Cable stop 1806-Z ni 1 pcs
KA7040200 - THERMIC CHOKE CONNECTION
KA7040200
C9993190H
C9997065B
C9997703B
C9997723
C9997816C
