FLIGHT DESIGN CT2K - Main Wheel, Detailed View

Chapter 4: Landing Gear
120
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number
Description
Q-ty per
ASSY
Unit
KA4020500 Main wheel 2 pcs
C9996083 Bolt DIN 912 M8x60-8.8 2 pcs
C9996336 Self-locking nut DIN 985-M8, regular 2 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 2 pcs
MAIN WHEEL, DETAILED VIEW
KA4020500
C9996083
C9996336
C9996505
