FLIGHT DESIGN CT2K - WA3010200 Stabilizer CTSW 2006

Chapter 3: Stabilizer & Rudder
90
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number
Description
Q-ty per
ASSY
Unit
KA3010001 Stabilizer axis of rotation 1 pcs
KA3010002 Stabilizer axis spacer 1 pcs
KA3010010 Stabilizer rotation bearing body 2 pcs
WA3010120
Stabilizer mounting pivot 1 pcs
WA3010200 Stabilator, CTSW 2006
1 pcs
WU3010200 Stabilator, CTSW 2006, reinforced
C9996259N Bolt DIN 931 M6x110-8.8 2 pcs
C9996333 Self-locking nut DIN 985-M5, regular 6 pcs
C9996334 Self-locking nut DIN 985-M6, regular 2 pcs
C9996336 Self-locking nut DIN 985-M8, regular 2 pcs
C9996504 Washer DIN 125 A2B-6.4mm 2 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 4 pcs
C9996563 Washer DIN 9021-5.3mm VZ 6 pcs
C9996259N
KA3010001
KA3010002
KA3010010
WA3010120
C9996207
C9996333
C9996334
C9996504
C9996336
C9996563
WA3010200 STABILIZER CTSW 2006 FIRST S/N 06-11-15
WA3010200
C9996505
WU3010200
