FLIGHT DESIGN CT2K - KA1030140 Handle

Chapter 1: Fuselage
36
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part Number Description
Q-ty per
ASSY
Unit
KA1030140 Handle 1 pcs
KA1030410 Forward rod 1 pcs
KA1030420 Rear rod 1 pcs
KA1030430 Lower rod 1 pcs
KA1030104 Tip 3 pcs
C9996259A Bolt DIN 931 M6x30-8.8 1 pcs
C9996506 Washer DIN 125 A-10.5mm VZ 1 pcs
C9996562 Washer DIN 9021-4.3 mm VZ 6 pcs
C9996803P Pin SBB04x11 6 pcs
C9996810F Cotter pins 2.0x16 6 pcs
C9997702G Compression spring 1x12x60 zinc plated 1 pcs
KA1030140
KA1030410
KA1030420
KA1030430
KA1030104
C9997702G
KA1030140 HANDLE
C9996803P
C9996810F
C9996562
C9996506
