FLIGHT DESIGN CT2K - KA5050100_2 Radiators

Chapter 5: Power Plant
151
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA5050102R
Part Number Description
Q-ty per
ASSY
Unit
KA5050102L Angle bracket 1 pcs
KA5050102R Angle bracket 1 pcs
KA5050104 Plate of Support 2(4) pcs
KA5050105 Bracket 1 pcs
KA5040013-01 Apron, Radiator 1 pcs
C9997790Y Couplet radiator 1 pcs
C9996783A Shock mount 60NR11 3 pcs
C9996334 Self-locking nut DIN 985-M6, regular 6 pcs
C9996504 Washer DIN 125 A2B-6.4mm 6 pcs
C9996092 Bolt DIN 912 M10x20-8.8 2 pcs
C9996511
Spring washer DIN7980 M10 mm VZ 2 pcs
KA5050102L
С9996334
С9996504
C9996092
KA5050104
C9997790Y
KA5040013-01
KA5050100_2 — RADIATORS FIRST S/N 05-05-08
С9996511
C9996783A
