Chapter 7: Systems
325
Release 5. Issue 21.January.2008Copyright © 2008 Flight Design GmbH. All Rights reserved
KS704010 - ROD INDEXING MECHANISM, ENGLISH VERSION
KS704010 - ROD INDEXING MECHANISM, GERMAN VERSION
Part
Number
Description
Q-ty per
ASSY
Unit
KS7040023 Body 1 pcs
KA7040020 Rod 1 pcs
KA7040021 Grip 1 pcs
C9996161 Screw ISO 7380 M5x12 2 pcs
C9996025 Bolt DIN 912 M4x16-8.8 1 pcs
Part
Number
Description
Q-ty per
ASSY
Unit
KB7040023 Body 1 pcs
KB7040024 Washer 2 pcs
KA7040020 Rod 2 pcs
C9996808 Cotter pin DIN 94 2x25 2 pcs
C9997702F Compression spring 1x10x32 zinc plated 1 pcs
KS7040023
C9996025
KA7040021
KA7040020
C9996161
KB7040024
C9996808
C9997702F
KA7040020
KS7040023
