FLIGHT DESIGN CT2K - KA4020100 Main Wheel Attachment

Chapter 4: Landing Gear
117
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4020100 MAIN WHEEL ATTACHMENT
Part Number Description
Q-ty per
ASSY
Unit
KA4020100L Main wheel attachment, left 1 pcs
KA4020100R Main wheel attachment, right 1 pcs
C9996058 Bolt DIN 912 M6x25-8.8 2 pcs
C9996083 Bolt DIN 912 M8x60-8.8 2 pcs
C9996336 Self-locking nut DIN 985-M8, regular 2 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 2 pcs
C9996509 Spring washer DIN7980 M6 mm VZ 2 pcs
C9996083
C9996058
C9996509
C9996336
C9996505
KA4020100L
KA4020100R
