Chapter 7: Systems
363
Release 5. Issue 21.January.2008Copyright © 2008 Flight Design GmbH. All Rights reserved
KA7053102
KA7053100 - LIGHT, LANDING, MOUNTING
Part
Number
Description
Q-ty per
ASSY
Unit
KA7053102 Plate 1 pcs
KA7053103 Cover 1 pcs
KA7053104 Spring 2 pcs
KA7053105 Bolt 2 pcs
KA7053109 Plate 1 pcs
С9997702C Compression spring 1x8x28.5x8.5 2 pcs
С9996025 Bolt DIN 912 M4x16-8.8 4 pcs
С9996167 Bolt DIN 912 M3x8-8.8 2 pcs
C9996331 Self-locking nut DIN 985-M3, regular 2 pcs
С9996333 Self-locking nut DIN 985-M5, regular 4 pcs
С9996502 Washer DIN 125 A2-4.3mm 4 pcs
С9996563A Washer DIN 9021-5.3mm A4 4 pcs
С9997131 Ball plug red 946 1 2 pcs
C9997173 Alluminium Reflector Lamp 100W, Halogen 1 pcs
C9997173A Socket for Alluminium Reflector Lamp 1 pcs
С9997703B Spring 0,5x5,0x25,0 2 pcs
KA7053103
С9997702C
С9996333
С9996563A
KA7053109
С9997131
С9996502
С9996167
С9996025
С9997703B
KA7053105
C9996331
C9997173A
C9997173
KA7053104
