Chapter 6: Flight Control
228
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Flap Control
Part
Number
Description
Q-ty per
ASSY
Unit
KA6030005 Bush 1 pcs
KA6030006 Safety plate 2 pcs
KA6030007 Bush 3 pcs
KA6030200 Transverse rod 1 pcs
KA6030300 T- bracket 1 pcs
KA6030310 Cable 1 pcs
KA6030400 Commutation unit 1 pcs
KA6060004 Bush 1 pcs
C9996025 Bolt DIN 912 M4x16-8.8 4 pcs
C9996042 Bolt DIN 912 M5x45-8.8 4 pcs
C9996060 Bolt DIN 912 M6x35-8.8 1 pcs
C9996064 Bolt DIN 912 M6x60-8.8 2 pcs
C9996083 Bolt DIN 912 M8x60-8.8 1 pcs
C9996207 Bolt DIN 7991 M5x16-8.8 1 pcs
C9996333 Self-locking nut DIN 985-M5, regular 5 pcs
C9996334 Self-locking nut DIN 985-M6, regular 3 pcs
C9996336 Self-locking nut DIN 985-M8, regular 1 pcs
C9996503 Washer DIN 125 A2-5.3mm 5 pcs
C9996504 Washer DIN 125 A2B-6.4mm 4 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 3 pcs
C9996563 Washer DIN 9021-5.3mm VZ 4 pcs
C9996565 Washer DIN 9021-6.4mm VZ 2 pcs
