FLIGHT DESIGN CT2K - C9997816 B Cable Stop; Copyright © 2008 Flight Design Gmbh. All Rights Reserved Release 5. Issue 21.January

To Next Page

To Previous Page

Chapter 6: Flight Control

274

C9997816B CABLE STOP

Part Number Derscription Q-ty per

ASSY

Unit

C9997816B Cable stop 621.1-Z15.2 zk 2 pcs

C9997816B
