FLIGHT DESIGN CT2K - KA7010000 - Installation of the Parachute Bag

Chapter 7: Systems
281
Release 5. Issue 21.January.2008Copyright © 2008 Flight Design GmbH. All Rights reserved
KA7010000 - INSTALLATION OF THE PARACHUTE BAG FIRST S/N 07-02-18
KA7010004
C9997831B
Part Number Description
Q-ty per
ASSY
Unit
KA7010003 Bracket 1 pcs
KA7010004 Bolt 2 pcs
КВ7010010_6 Support of Rescue System 1 pcs
C9996334 Self-locking nut DIN 985-M6, regular 2 pcs
C9996504 Washer DIN 125 A2B-6.4mm 2 pcs
C9997831B Rescue System BRS1050 1 set
C9996504
C9996334
KA7010003
part of set C9997831B
КВ7010010_6
