FLIGHT DESIGN CT2K - Warp Drive Three Blade Propeller

Chapter 5: Power Plant
166
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Warp Drive Three Blade Propeller
Part Number Description
Q-ty per
ASSY
Unit
KA5090001-01 Propeller spacer 1 pcs
KA5090002 Bush 6 pcs
KA5090003-01 Bush 6 pcs
KS5080004 Spinner axis 1 pcs
KA5090100-01 Spinner 1 pcs
KA5090200-01 Spinner supporting disk 1 pcs
KA5090007-01 Ring 1 pcs
C9996035 Bolt DIN 912 M5x16-8.8 2 pcs
C9996063 Bolt DIN 912 M6x50-8.8 12 pcs
C9996161 Screw ISO 7380 M5x12 6 pcs
C9996260 Bolt DIN 931 M8x130-8.8 6 pcs
C9996334 Self-locking nut DIN 985-M6, regular 12 pcs
C9996336 Self-locking nut DIN 985-M8, regular 6 pcs
C9996503 Washer DIN 125 A2-5.3mm 2 pcs
C9996504 Washer DIN 125 A2B-6.4mm 24 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 12 pcs
C9997796 Propeller Warp Drive 3 bladed 66’’ 1 set
