FLIGHT DESIGN CT2K - KA4020200 Upper Mounting Unit; KA4020300 Bracket for Main Gear Fairing

Chapter 4: Landing Gear
114
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4020300 BRACKET FOR MAIN GEAR FAIRING
Part
Number
Description
Q-ty per
ASSY
Unit
KA4020300 Bracket of main strut fairing 2 pcs
C9996037 Bolt DIN 912 M5x20-8.8 2 pcs
KA4020200 UPPER MOUNTING UNIT
Part
Number
Description
Q-ty per
ASSY
Unit
KA4020200 Upper mouting unit 1 pcs
C9996060
Bolt DIN 912
M6x35-8.8
12 pcs
C9996284B
Bolt DIN 933
M6x20-8.8
4 pcs
C9996334
Self-locking nut DIN
985-M6, regular
8 pcs
C9996504
Washer DIN 125
A2B-6.4mm
8 pcs
С9996565
Washer DIN 9021-
6.4mm VZ
8 pcs
KA4020300
C9996037
C9996060
C9996504 C9996334 KA4020200
С9996565C9996284B
