Chapter 4: Landing Gear
113
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4020000 - Main landing gear
Part Number Description
Q-ty
per
ASSY
Unit
KA4020001 Main spring bar 2 pcs
KA1000410L Rear reinforcement, left 1 pcs
KA1000410R Rear reinforcement, right 1 pcs
KA4020010L Main wheel fairing, left 1 pcs
KA4020010R Main wheel fairing, right 1 pcs
KU4020010L Main wheel fairing, left 1 pcs
KU4020010R Main wheel fairing, right 1 pcs
KA4020100L Main wheel attachment, left 1 pcs
KA4020100R Main wheel attachment, right 1 pcs
KA4020110
Spacer 2 pcs
KA4020200 Upper mouting unit 1 pcs
KA4020300 Bracket of main strut fairing 2 pcs
KA4020400L Main strut fairing, left 1 pcs
KA4020400R Main strut fairing, right 1 pcs
KU4020400L Main strut fairing, left 1 pcs
KU4020400R Main strut fairing, right 1 pcs
KA4020450 Fairing 2 pcs
KA4020500 Main wheel 2 pcs
С9993189T Door seal 0.9 pcs
C9996037 Bolt DIN 912 M5x20-8.8 4 pcs
C9996058 Bolt DIN 912 M6x25-8.8 16 pcs
C9996060 Bolt DIN 912 M6x35-8.8 12 pcs
C9996083 Bolt DIN 912 M8x60-8.8 6 pcs
C9996161 Screw ISO 7380 M5x12 6 pcs
C9996162A Screw ISO 7380 M5x16 4 pcs
C9996260 Bolt DIN 931 M8x130-8.8 2 pcs
C9996284B Bolt DIN 933 M6x20-8.8 10 pcs
C9996334 Self-locking nut DIN 985-M6, regular 34 pcs
C9996336 Self-locking nut DIN 985-M8, regular 8 pcs
C9996503 Washer DIN 125 A2-5.3mm 12 pcs
C9996504 Washer DIN 125 A2B-6.4mm 26 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 6 pcs
C9996509 Spring washer DIN7980 M6 mm VZ 10 pcs
C9996562 Washer DIN 9021-4.3 mm VZ 8 pcs
C9996565 Washer DIN 9021-6.4mm VZ 44 pcs
C9996567 Washer DIN 9021-8.4mm VZ 4 pcs
C9996650 Stainl. steel rivet A2 4x7.5 4 pcs
