Chapter 6: Flight Control
178
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
CHAPTER 6: FLIGHT CONTROL
Engine Control
Part Number Description
Q-ty per
ASSY
Unit
KA6010100 Throttle box 1 pcs
C9993192 Cable housing 1.9x5.0 4.4 m
C9996035 Bolt DIN 912 M5x16-8.8 4 pcs
C9996037 Bolt DIN 912 M5x20-8.8 2 pcs
C9996039 Bolt DIN 912 M5x30-8.8 2 pcs
C9996042 Bolt DIN 912 M5x45-8.8 1 pcs
C9996161 Screw ISO 7380 M5x12 4 pcs
C9996333 Self-locking nut DIN 985-M5, regular 11 pcs
C9996336 Self-locking nut DIN 985-M8, regular 2 pcs
C9996503 Washer DIN 125 A2-5.3mm 5 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 4 pcs
C9996563 Washer DIN 9021-5.3mm VZ 2 pcs
C9996650 Stainl. steel rivet A2 4x7.5 2 pcs
C9997065B Steel rope 7x7 1 mm 5.1 m
C9997816B Cable stop 621.1-Z15.2 zk 1 pcs
C9997816C Cable stop 1806-Z ni 2 pcs
